What are the basic knowledge of plastic molds and injection molds?
The innovation of plastic mold processing technology, the widespread application of various new mold materials, and the standardization and specialization of mold parts force us to speed up the design speed and adapt to the development of molds.
The improvement of speed requires the design section to be completed in about 3 days; the improvement of plastic mold precision requires that the processing methods of each part should be clearly considered during the design process, and the processing methods with high precision and low processing cost should be adopted as much as possible. The improvement of precision and speed are common. The improvement of speed must require the improvement of precision; the improvement of precision must lead to the improvement of speed.
1. Structural system: template, support column, limit column, etc.
2. Molding system: female mold core, male mold core, insert, etc.
3. Casting system: main flow channel, branch flow channel, gate, cold slag well, etc.
4. Guide positioning system: guide column, guide sleeve, zero degree fine positioning, taper fine positioning, etc.
5. Ejection system: ejector, cylinder needle, push plate, gas ejector, thread ejector, compound ejector, etc.
6. Temperature control system: water channel, water tower, nozzle, etc.
7. Exhaust system: parting surface exhaust, insert exhaust, ejector exhaust, steel exhaust, etc.
8. Core pulling system: front mold core pulling, rear core pulling, inclined ejector, etc.
9. Standard parts system: screws, sleeves, waterproof rings, etc.
10. Safety reset system: micro switch, forced reset, etc.
